800-1800mm Non-Woven / Woven Fabric Aluminum Foil Kraft Paper Extrusion Coating Lamination Machine
800-1800mm Non-Woven / Woven Fabric Aluminum Foil Kraft Paper Extrusion Coating Lamination Machine
PE Extrusion Film Laminating Extrusion Machine
Width:1600mm
Apply Coating Resin:LDPE/PP And Other Coating
Film Width:1500-600mm
Application:Extrusion Coating Lamination Machine For Non Woven/Woven Fabric
Whatsapp:+8617331527289
Delivery Time:45 Working Days
- Description
- Inquiry
Product Description
The Extrusion Laminating Machine model laminating double side, multi-layers for time is independent research and development by YF Industry.This type of machine has been widely used for substrates such as paper,non woven fabric,aluminum foil, thin film,etc that needs to be multi-layer lamination at one time. This is the right machine for laminating.the laminated packaging materials such as double-side laminated paper cup, disposable milk and aseptic paper-plastic aluminum box, and photo paper, aluminum lamination, 6 layer paper-plastic etc.
| Model | YFLM-1600 |
| Using Material | Paper(60-500g/m2) |
| Using Lamination Material | BOPP Film, PET, OPP, etc. (On second unwind unit) |
| Using Coating Resin | LDPE, PE, PP, EVA, PLA, etc. |
| Working Speed | 1-200m/min |
| PLA: Max. speed 80m/min | |
| Working Width | 800-1500mm |
| Guide roller width | 1600mm |
| Coating Thickness | PLA: 22-30g / m2 |
| Film Thickness | 0.012mm ~ 0.050mm |
| Uniformity of Thickness | <±5% |
| Core size | 76mm |
| Max. Unwinding Diameter | 1500mm |
| Max. Rewinding Diameter | 1200mm |
| Lamination Cooling Roller | Φ500x1800mm |
| Tension Control | Automatic tension control |
| Electric Control Way | PLC control, man-machine interface operation |
| Drive Motors | AC frequency conversion motor, asynchronous electric motor and gear motor |
| Frequency | Import AC digital vector control frequency converter |
| Cooling Water | Temperature is 20-25°c, flow rate is 30 m3/h, and water pressure is above 2 kg /cm2 |
| Compressed Air | Pressure is above 5kg / cm2 |
| Extruder Heating Way | Electricity |
| Oven Heating Way | Electricity |
| Power supply | Three-phase 380-415V, single-phase 220V,50HZ |
| Weight | About 13T |
| Fixing Size L*W*H | 9000mm × 11000mm × 3600mm |
| Color | Factory standard or can be chosen by buyer |
Feature
1.Imported high precision T-Die.
2.Extruder; Automatically temperature control and material feeding.
3.Triplicate roller extrusion laminatbn device to ensure the quality and efficiency of machine.
4.Whole machine with fully automatic tension control.
5.The Unwinding Device,Laminating Device and Rewinding Device synchronized auto control.
6. PLC programmable control,man-machine interface operation.
Advantages
1.All photo was taken from actual products.
2. We can print client’s logo on our machine if needed.
3. Our machine specification can be developed as requests,
4. All of our machine with assured quality and competitive price.
5. Fast & Timely delivery is our merits.
6. After-sales was provided.
Why Choose Our Machine?
Specialized design for car cover fabric manufacturers
Stable operation for PE extrusion coating lamination
Suitable for multi-layer car cover fabric production
Cost-effective solution for large-scale production
Professional installation guidance and after-sales service
Specialized for car cover fabric extrusion coating + lamination
Reliable quality for long-term outdoor car cover materials
Cost-effective solution for professional manufacturers
Customized design according to production needs
