Extrusion Coating Lamination Machine PET Sheet Extruder Machine
YF-1700 PE Film Non Woven Kraft Paper Aluminum Film PE Laminating Coating Machine
HDPE Extrusion Machine Plastic Film Extrusion Machine
Width:1700mm
Apply Coating Resin:LDPE/PP And Other Coating
Film Width:1600-600mm
Application:Extrusion Coating Lamination Machine for Car Cover Fabric
Whatsapp:+8617331527289
Delivery Time:45 Working Days
- Description
- Inquiry
Product Description
Laminating machine for paper non woven fabric aluminum foil coating, protective clothing coating machine
This extrusion laminating machine using LDPE, HDPE, PP, EVA etc. As raw material, it processes by melting the plastic for extruding form the T die mould and finally laminating with the base material, this type of machine has been widely used for the lamination of substrates such as paper, non woven fabric, non woven fabric, woven fabric, aluminum foil, BOPP film etc. The finished product is famous for its high fastness, uniformity of thickness and high sealed capability, all these have contribute of make this type of machine become one of the most popular and valuable extrusion laminating machines in domestic market and abroad.
| Model | YFLM-1800 |
| Using Material | Paper(60-500g/m2) |
| Using Lamination Material | BOPP Film, PET, OPP, etc. (On second unwind unit) |
| Using Coating Resin | LDPE, PE, PP, EVA, PLA, etc. |
| Working Speed | 1-200m/min |
| PLA: Max. speed 80m/min | |
| Working Width | 800-1700mm |
| Guide roller width | 1800mm |
| Coating Thickness | PLA: 22-30g / m2 |
| Film Thickness | 0.012mm ~ 0.050mm |
| Uniformity of Thickness | <±5% |
| Core size | 76mm |
| Max. Unwinding Diameter | 1500mm |
| Max. Rewinding Diameter | 1200mm |
| Lamination Cooling Roller | Φ500x1800mm |
| Tension Control | Automatic tension control |
| Electric Control Way | PLC control, man-machine interface operation |
| Drive Motors | AC frequency conversion motor, asynchronous electric motor and gear motor |
| Frequency | Import AC digital vector control frequency converter |
| Cooling Water | Temperature is 20-25°c, flow rate is 30 m3/h, and water pressure is above 2 kg /cm2 |
| Compressed Air | Pressure is above 5kg / cm2 |
| Extruder Heating Way | Electricity |
| Oven Heating Way | Electricity |
| Power supply | Three-phase 380-415V, single-phase 220V,50HZ |
| Weight | About 13T |
| Fixing Size L*W*H | 9000mm × 11000mm × 3600mm |
| Color | Factory standard or can be chosen by buyer |
Extrusion Coating Lamination Machine for Car Cover Fabric
Professional Machine for High-Quality Car Cover Material Production
Our Extrusion Coating Lamination Machine for Car Cover Fabric is specially designed for the production of laminated car cover materials, combining plastic extrusion, coating, and lamination into one continuous process. It is ideal for manufacturing waterproof, UV-resistant, and durable car cover fabrics for outdoor and long-term vehicle protection.
This machine is widely used to laminate nonwoven fabric or woven fabric with PE film, producing strong, stable, and weather-resistant car cover materials.
Suitable Raw Materials
- PE / LDPE / LLDPE / HDPE
- EVA and modified PE/PP
- Spunlace nonwoven fabric
- Woven fabric
- PE film for car cover fabric
- High-efficiency single screw extruder
- Precision T-die for extrusion coating
- Stable lamination and pressure control system
- Effective cooling and edge trimming unit
- Automatic winding system
- Easy operation and maintenance
Why Choose Our Machine?
Specialized design for car cover fabric manufacturers
Stable operation for PE extrusion coating lamination
Suitable for multi-layer car cover fabric production
Cost-effective solution for large-scale production
Professional installation guidance and after-sales service
Specialized for car cover fabric extrusion coating + lamination
Reliable quality for long-term outdoor car cover materials
Cost-effective solution for professional manufacturers
Customized design according to production needs
