PE Film Non Woven Kraft Paper Aluminum Film PE Laminating Coating Machine
YF-1700 PE Film Non Woven Kraft Paper Aluminum Film PE Laminating Coating Machine
HDPE Extrusion Machine Plastic Film Extrusion Machine
Width:1700mm
Apply Coating Resin:LDPE/PP And Other Coating
Film Width:1600-600mm
Application:Extrusion Coating Lamination Machine for Car Cover Fabric
Whatsapp:+8617331527289
Delivery Time:45 Working Days
- Description
- Inquiry
Product Description
This series green laminator, paper plastic composite units (no adhesive composition unit), is integrated with off-loading, drying, surface treatment, composite, cutting edge, discharge and rewinding as a whole; adapts photoelectric web guiding, corona treatment, line speed, feed length digital display; automatic constant tensile force, temperature self-control and advanced technology. widely used in paper packing field,such as paper cup,paper bowel, snack plate, paper bag, release paper and so on
| Model | YFLM-1800 |
| Using Material | Paper(60-500g/m2) |
| Using Lamination Material | BOPP Film, PET, OPP, etc. (On second unwind unit) |
| Using Coating Resin | LDPE, PE, PP, EVA, PLA, etc. |
| Working Speed | 1-200m/min |
| PLA: Max. speed 80m/min | |
| Working Width | 800-1700mm |
| Guide roller width | 1800mm |
| Coating Thickness | PLA: 22-30g / m2 |
| Film Thickness | 0.012mm ~ 0.050mm |
| Uniformity of Thickness | <±5% |
| Core size | 76mm |
| Max. Unwinding Diameter | 1500mm |
| Max. Rewinding Diameter | 1200mm |
| Lamination Cooling Roller | Φ500x1800mm |
| Tension Control | Automatic tension control |
| Electric Control Way | PLC control, man-machine interface operation |
| Drive Motors | AC frequency conversion motor, asynchronous electric motor and gear motor |
| Frequency | Import AC digital vector control frequency converter |
| Cooling Water | Temperature is 20-25°c, flow rate is 30 m3/h, and water pressure is above 2 kg /cm2 |
| Compressed Air | Pressure is above 5kg / cm2 |
| Extruder Heating Way | Electricity |
| Oven Heating Way | Electricity |
| Power supply | Three-phase 380-415V, single-phase 220V,50HZ |
| Weight | About 13T |
| Fixing Size L*W*H | 9000mm × 11000mm × 3600mm |
| Color | Factory standard or can be chosen by buyer |
Extrusion Coating Lamination Machine for Car Cover Fabric
Professional Machine for High-Quality Car Cover Material Production
Our Extrusion Coating Lamination Machine for Car Cover Fabric is specially designed for the production of laminated car cover materials, combining plastic extrusion, coating, and lamination into one continuous process. It is ideal for manufacturing waterproof, UV-resistant, and durable car cover fabrics for outdoor and long-term vehicle protection.
This machine is widely used to laminate nonwoven fabric or woven fabric with PE film, producing strong, stable, and weather-resistant car cover materials.
Suitable Raw Materials
- PE / LDPE / LLDPE / HDPE
- EVA and modified PE/PP
- Spunlace nonwoven fabric
- Woven fabric
- PE film for car cover fabric
- PLC man-machine interface centralized control, machine, electricity, gas, integrated design.
- High efficient corona device, hydraulic for the network, are the first domestic, can effectively enhance the product peel strength.
- It can be equipped with a second unwinding frame to realize paper-film compounding,paper-alu compounding,paper-paper compounding.
Why Choose Our Machine?
Specialized design for car cover fabric manufacturers
Stable operation for PE extrusion coating lamination
Suitable for multi-layer car cover fabric production
Cost-effective solution for large-scale production
Professional installation guidance and after-sales service
Specialized for car cover fabric extrusion coating + lamination
Reliable quality for long-term outdoor car cover materials
Cost-effective solution for professional manufacturers
Customized design according to production needs
